8 Mbit Firmware Hub
A Microchip Technology Company
SST49LF008A
Data Sheet
ping and paging, please refer to the Intel 82801(ICH) I/O Controller Hub documentation. Since there is
no ID support in PP Mode, to program multiple devices a stand-alone PROM programmer is recom-
mended.
Registers
There are three types of registers available on the SST49LF008A, the General Purpose Inputs regis-
ter, Block Locking registers and the JEDEC ID registers. These registers appear at their respective
address location in the 4 GByte system memory map. Unused register locations will read as 00H.
Attempts to read or write to any registers during internal Write operations will be ignored.
General Purpose Inputs Register
The GPI_REG (General Purpose Inputs Register) passes the state of FGPI[4:0] pins at power-up on
the SST49LF008A. It is recommended that the FGPI[4:0] pins are in the desired state before FWH4 is
brought low for the beginning of the bus cycle, and remain in that state until the end of the cycle. There
is no default value since this is a pass-through register. The GPI register for the boot device appears at
FFBC0100H in the 4 GByte system memory map, and will appear elsewhere if the device is not the
boot device. Register is not available for read when the device is in Erase/Program operation. See
Table 5 for the GPI_REG bits and function.
Table 5: General Purpose Inputs Register
Pin #
Bit
7:5
4
Function
Reserved
FGPI[4]
32-PLCC
-
30
32-TSOP
-
6
40-TSOP
-
7
Reads status of general
purpose input pin
3
FGPI[3]
3
11
15
Reads status of general
purpose input pin
2
FGPI[2]
4
12
16
Reads status of general
purpose input pin
1
FGPI[1]
5
13
17
Reads status of general
purpose input pin
0
FGPI[0]
6
14
18
Reads status of general
purpose input pin
T5.3 25085
?2011 Silicon Storage Technology, Inc.
14
DS25085A
10/11
